Slurry knife Edge Gate Valve

The Slurry Knife Edge Gate Valve is a robust industrial valve designed for handling water in various industrial applications. With a port size ranging from 2" to 24", this valve is suitable for medium to large-scale operations. It operates using pneumatic power, ensuring efficient and reliable performance. Constructed from high-quality stainless steel, this valve offers durability and corrosion resistance. With pressure ratings of 150 psi and 300 psi, it can accommodate a wide range of operational pressures, making it a versatile choice for industrial settings. Its distinctive green color adds visibility and aesthetics to the valve, making it easy to identify and maintain.

Features:-

• Full Port Flow Design: - Full port design for greater flow capacity, minimum pressure drop & eliminates turbulence.
• No Internal Cavities: - Sleeve design is eliminates internal seat cavities. Gate banding, failure of valve & many problems occur due to seal cavity.
• Eliminate Gland Packing: - Sleeves are seals against each other so no required any Gland packing.
• No Contact between Valve & Slurry: - Sleeve design completely isolated the valve housing & Gaskets cover the other open metal surface from the slurry flow.
• Bi-Directional: - Due to double sleeves design valve is sealed against line pressure in either direction.
• Less maintenance cost: - As compared others gate valve our valve have not wearing parts. Only elastomer is requiring at the time of maintenance.
• Gate Lubrication System: - Lubrication seal is provided for continues lubrication of gate plate. Seal is full of silicon based lubricant. Gate is passes through the lubricant seal.

Technical Information

• Body Type            : Bi-Directional
• Port                       : Full Round Port
• Size Range            : 2 to 24 (50NB to 600 NB) Higher on order.
• End Connection    : wafer style with BSP threaded hole in chest Area and through holes.
• Pressure Rating     : 150 psi  and  300 psi
• Temperature Rating: < 200oC
• Drilling                  : As per ANSI B 16.5, other on as per Requirement.

Material options

• Body           : C.S, C.I, S.S-316, S.S-304, other on order.
• Gate Plate   : SS-316, SS-304, Hast Alloy, other on order.

Material of elastomer & Seal

• Neoprene,
• Viton or Silicone
• EPDM
• Food Quality for hygienic application
• Natural Rubber
• Gum Rubber

Operation : Manual Hand Wheel / Bevel Gear / Pneumatic Cylinder (Double / Single Acting) / Hydraulic Cylinder / Electric Actuator Operated
